Meritec’s SFF-8470 NX is the highest bandwidth system available using the SFF-8470 connector. The SFF-8470 cable plug with it Direct Attach cable termination technology when mated with the SFF-8473 board receptacle with its unique shielding and footprint design provide a virtually transparent signal path at 10Gb/s. Other NX Interconnect Products: 4X (SFF-8470) Embedded within MIL-C-38999, NX+ Board Mount Receptacles (SFF-8473 4X & 12X).

VIEW THE FLIPPABLE HIGH BANDWIDTH NX CATALOG

4X NX

986111-010

4X Straight to Straight, Latch style, IB cable assembly
Contacts: 16
Diff. Pairs: 8
Spares: 8
Retention: Latch
Wire AWG: 24
Length: 10 Meters
Plating: 30µ Au min./50µ Ni min.
Wiring: Pin 1 to 16

4X NX

986121-007

4X Straight to Straight, Latch style, IB cable assembly
Contacts: 16
Diff. Pairs: 8
Spares: 0
Retention: Latch
Wire AWG: 26
Length: 7 Meters
Plating: 30µ Au min./50µ Ni min.
Wiring: Pin 1 to 16

4X NX

986131-005

4X Straight to Straight, Latch style, IB cable assembly
Contacts: 16
Diff. Pairs: 8
Spares: 0
Retention: Latch
Wire AWG: 28
Length: 5 Meters
Plating: 30µ Au min./50µ Ni min.
Wiring: Pin 1 to 16

4X NX

986131-003

4X Straight to Straight, Latch style, IB cable assembly
Contacts: 16
Diff. Pairs: 8
Spares: 0
Retention: Latch
Wire AWG: 28
Length: 3 Meters
Plating: 30µ Au min./50µ Ni min.
Wiring: Pin 1 to 16

4X NX

986131-002

4X Straight to Straight, Latch style, IB cable assembly
Contacts: 16
Diff. Pairs: 8
Spares: 0
Retention: Latch
Wire AWG: 28
Length: 2 Meters
Plating: 30µ Au min./50µ Ni min.
Wiring: Pin 1 to 16

4X NX

986131-001

4X Straight to Straight, Latch style, IB cable assembly
Contacts: 16
Diff. Pairs: 8
Spares: 0
Retention: Latch
Wire AWG: 28
Length: 1 Meters
Plating: 30µ Au min./50µ Ni min.
Wiring: Pin 1 to 16

4X NX

986131-000.5

4X Straight to Straight, Latch style, IB cable assembly
Contacts: 16
Diff. Pairs: 8
Spares: 0
Retention: Latch
Wire AWG: 28
Length: .5 Meters
Plating: 30µ Au min./50µ Ni min.
Wiring: Pin 1 to 16

4X NX

986141-000.5

4X Straight to Straight, Latch style, IB cable assembly
Contacts: 16
Diff. Pairs: 8
Spares: 0
Retention: Latch
Wire AWG: 30
Length: .5 Meters
Plating: 30µ Au min./50µ Ni min.
Wiring: Pin 1 to 16

4XNXReceptacles

983722AL AN 2QMF

4X Receptacle, Right Angle, Latch
Contacts: 16
Diff. Pairs: 8
Spares: 0
Hold Down: Screws
SMT: Yes
Pick & Place Tab: No
Plating: 30µ Au min./50µ Ni min.

4XNXReceptacles

983722ALAP2QMF

4X Receptacle, Right Angle, Latch
Contacts: 16
Diff. Pairs: 8
Spares: 0
Hold Down: Screws
SMT: Yes
Pick & Place Tab: Yes
Plating: 30µ Au min./50µ Ni min.

4XNXReceptacles

983722ALBN2QMF

4X Receptacle, Right Angle, Latch
Contacts: 16
Diff. Pairs: 8
Spares: 0
Hold Down: Sdr Posts
SMT: Yes
Pick & Place Tab: No
Plating: 30µ Au min./50µ Ni min.

4XNXReceptacles

983722ALBP2QMF

4X Receptacle, Right Angle, Latch
Contacts: 16
Diff. Pairs: 8
Spares: 0
Hold Down: Sdr Posts
SMT: Yes
Pick & Place Tab: Yes
Plating: 30µ Au min./50µ Ni min.

4XNXReceptacles

983722ALCN2QMF

4X Receptacle, Right Angle, Latch
Contacts: 16
Diff. Pairs: 8
Spares: 0
Hold Down: Screw W/Top Panel Mnt
SMT: Yes
Pick & Place Tab: No
Plating: 30µ Au min./50µ Ni min.

4XNXReceptacles

983722ALCP2QMF

4X Receptacle, Right Angle, Latch
Contacts: 16
Diff. Pairs: 8
Spares: 0
Hold Down: Screw W/Top Panel Mnt
SMT: Yes
Pick & Place Tab: Yes
Plating: 30µ Au min./50µ Ni min.

4XNXReceptacles

983722ALDN2QMF

4X Receptacle, Right Angle, Latch
Contacts: 16
Diff. Pairs: 8
Spares: 0
Hold Down: Sdr Post W/Top Panel Mnt
SMT: Yes
Pick & Place Tab: No
Plating: 30µ Au min./50µ Ni min.

4XNXReceptacles

983722ALDP2QMF

4X Receptacle, Right Angle, Latch
Contacts: 16
Diff. Pairs: 8
Spares: 0
Hold Down: Sdr Post W/Top Panel Mnt
SMT: Yes
Pick & Place Tab: Yes
Plating: 30µ Au min./50µ Ni min.

Screen Shot 2015-02-20 at 12.17.49 PM

983922AL AN 2QMF

12X Receptacle, Right Angle, Latch
Contacts: 48
Diff. Pairs: 24
Spares: 0
Hold Down: Screws
SMT: Yes
Pick & Place Tab: No
Plating: 30µ Au min./50µ Ni min.

Screen Shot 2015-02-20 at 12.17.49 PM

983922ALAP2QMF

12X Receptacle, Right Angle, Latch
Contacts: 48
Diff. Pairs: 24
Spares: 0
Hold Down: Screws
SMT: Yes
Pick & Place Tab: Yes
Plating: 30µ Au min./50µ Ni min.

Screen Shot 2015-02-20 at 12.17.49 PM

983922ALBN2QMF

12X Receptacle, Right Angle, Latch
Contacts: 48
Diff. Pairs: 24
Spares: 0
Hold Down: Sdr Posts
SMT: Yes
Pick & Place Tab: No
Plating: 30µ Au min./50µ Ni min.

Screen Shot 2015-02-20 at 12.17.49 PM

983922ALBP2QMF

12X Receptacle, Right Angle, Latch
Contacts: 48
Diff. Pairs: 24
Spares: 0
Hold Down: Sdr Posts
SMT: Yes
Pick & Place Tab: Yes
Plating: 30µ Au min./50µ Ni min.

Screen Shot 2015-02-20 at 12.17.49 PM

983922ALCN2QMF

12X Receptacle, Right Angle, Latch
Contacts: 48
Diff. Pairs: 24
Spares: 0
Hold Down: Screw W/Top Panel Mnt
SMT: Yes
Pick & Place Tab: No
Plating: 30µ Au min./50µ Ni min.

Screen Shot 2015-02-20 at 12.17.49 PM

983922ALCP2QMF

12X Receptacle, Right Angle, Latch
Contacts: 48
Diff. Pairs: 24
Spares: 0
Hold Down: Screw W/Top Panel Mnt
SMT: Yes
Pick & Place Tab: Yes
Plating: 30µ Au min./50µ Ni min.

Screen Shot 2015-02-20 at 12.17.49 PM

983922ALDN2QMF

12X Receptacle, Right Angle, Latch
Contacts: 48
Diff. Pairs: 24
Spares: 0
Hold Down: Sdr Post W/Top Panel Mnt
SMT: Yes
Pick & Place Tab: No
Plating: 30µ Au min./50µ Ni min.

Screen Shot 2015-02-20 at 12.17.49 PM

983922ALDP2QMF

12X Receptacle, Right Angle, Latch
Contacts: 48
Diff. Pairs: 24
Spares: 0
Hold Down: Sdr Post W/Top Panel Mnt
SMT: Yes
Pick & Place Tab: Yes
Plating: 30µ Au min./50µ Ni min.

4XFeedThruNX

984001-004-T

4X Feed-Thru, Thumbscrew to Thumbscrew
Contacts: 16
Diff. Pairs: 8
Spares: 0
Hold Down: Panel Mount
SMT: N/A
Pick & Place Tab: N/A
Plating: 30µ Au min./50µ Ni min.

4XFeedThruNX

984001-004-L

4X Feed-Thru, Latch to Latch
Contacts: 16
Diff. Pairs: 8
Spares: 0
Hold Down: Panel Mount
SMT: N/A
Pick & Place Tab: N/A
Plating: 30µ Au min./50µ Ni min.

4XFeedThruNX

984001-004-LTS

4X Feed-Thru, Latch to Thumbscrew
Contacts: 16
Diff. Pairs: 8
Spares: 0
Hold Down: Panel Mount
SMT: N/A
Pick & Place Tab: N/A
Plating: 30µ Au min./50µ Ni min.

4XFeedThruNX

984001-004-TSL

4X Feed-Thru, Thumbscrew to Latch
Contacts: 16
Diff. Pairs: 8
Spares: 0
Hold Down: Panel Mount
SMT: N/A
Pick & Place Tab: N/A
Plating: 30µ Au min./50µ Ni min.

Features & Benefits

  • Industry standard interface for IB and Ethernet CX-4
  • Available in Latch and Thumbscrew retention
  • Low Smoke, Zero Halogen Jacketed (LSZH)
  • Cable available in 24, 26, 28, 30 AWG, high bandwidth
  • Supports data rates to 10 Gbs and differential-pair signaling with low-skewpairs & shielding for EMI/RFI protection
  • UL listed components
  • RoHS compliant
